Leading manufacturer of retractable cables
At Custom Designed Cables, we design and manufacture custom retractable cables for industries ranging from automotive and aerospace to medical devices and industrial machinery. With over 20 years of cable manufacturing expertise and more than 6,000 bespoke cable designs completed to date, we build retractable cables that keep performing through repeated extension and retraction in high-use environments.
Retractable cables are also known as coiled cables, curly cables or spiral cables. They’re the solution of choice where space is limited, where equipment moves between two points, or where a cable needs to extend quickly and then return to a tidy resting length. Every retractable cable we produce is manufactured in the UK within an ISO 9001:2015-certified quality management system, with UL and CSA-approved options available.
What is a retractable cable?
A retractable cable is formed into a helical coil, allowing it to stretch and then return to its original shape. Compared with a standard straight cable, a retractable cable reduces strain on connectors, improves mobility and helps to prevent tangling.
Retractable cables can be designed for low-voltage electronics, heavy-duty power supply or data transmission, including coiled versions of our data cables. Depending on the material and application, extension lengths can reach up to 30 m, with coil diameters from 5 mm to 400 mm.
Benefits of retractable cables
Retractable and coiled cables offer several advantages over straight cable constructions:
- Space saving: A compact coil when the cable isn’t in use.
- Flexibility: The cable extends and retracts without being placed under mechanical stress.
- Durability: Designed to withstand repeated extension cycles over a long service life.
- Safety: Fewer trip hazards and tidier cable management.
- Customisation: Available in different colours and coil diameters, with optional jacket printing.
Materials for custom retractable cables
Choosing the right jacket material is essential for flexibility and long-term performance. Each of the materials below suits a different type of operating environment, and our team will help you select the right one for your application.
PVC (polyvinyl chloride)
PVC cable is the most cost-effective option for retractable cables. It performs well in general-purpose and indoor applications where exposure to chemicals, heat and mechanical stress is limited, such as office equipment and light-duty electronics.
PUR (polyurethane)
PUR cable is highly flexible and extremely resistant to abrasion and chemicals. This makes it the preferred choice for robotics, automation and industrial machinery where cables are in constant movement. PUR retractable cables retain their elasticity even after thousands of cycles.
LSZH (low smoke zero halogen)
LSZH cable is designed for public spaces and regulated industries where fire safety is critical. In the event of a fire, LSZH materials release very little smoke and no toxic halogen gases, helping to protect people and sensitive equipment. LSZH retractable cables are widely used in medical equipment and building infrastructure.
Hytrel
Hytrel is an advanced thermoplastic that combines flexibility with exceptional toughness. It offers a longer extension range than PVC and high resistance to mechanical stress, so it’s often selected for aerospace and outdoor applications where cables must keep their elasticity in harsh conditions.
Retractable cable design options
Alongside the jacket material, every retractable cable can be tailored to the equipment it connects. Design options include:
- Coil diameters from 5 mm to 400 mm
- Extension lengths up to 30 m
- Stripped ends for easier installation
- Jacket colour matching and cable printing for branding or identification
- Multicore cable layouts for combined power and data
Applications for retractable cables
Retractable cables are versatile and can be tailored to the specific needs of each industry. Example applications include:
- Automotive and transport: Diagnostic equipment, charging systems and trailer connections, where coiled automotive cables keep vehicles safe and organised. Retractable extension cables are also common in workshops for powering tools while keeping the floor clear.
- Electric vehicle charging: Retractable EV cables help reduce clutter at charging points and allow for safe, compact storage.
- Medical devices: Hospital equipment such as diagnostic carts and monitoring and imaging systems, where LSZH and PUR jackets support hygiene and fire safety requirements.
- Aerospace and defence: Aircraft and military cables for field equipment, where coiled cables must withstand vibration, movement and extreme conditions. PUR and Hytrel offer the durability required for mission-critical use.
- Industrial and manufacturing: Assembly lines, robotic systems and inspection equipment, where retractable power cables help reduce downtime by preventing tangled or damaged cables.
- Telecommunications: Mobile communication units and server rooms, where coiled cables provide flexibility for temporary or mobile connections.

How to specify a custom retractable cable
To provide custom cable design that suits your application, our team will ask for the following details:
- Length and finish of the first tail
- Overall diameter of the coil
- Retracted length, or length at rest
- Diameter of the stripped end
- Length and finish of the second tail
- Quantity required
- Cable description, including the number of cores, conductor sizes and any special requirements
Our design team will then confirm feasibility, advise on the most suitable materials and provide a quote.
Lead times and quality
Lead times vary depending on the cable construction, the availability of materials and any minimum order quantities set by our material suppliers. We’ll confirm the lead time and any minimum order quantity for your project when we provide your quote, and we always work to turn projects around as quickly as possible.
All of our retractable cables are produced at our manufacturing site in Bolton to national and international standards. Our custom cable manufacturing is carried out within an ISO 9001:2015-certified quality management system, with UL and CSA approvals, and we maintain compliance with RoHS and REACH regulations.
Why choose Custom Designed Cables?
Our excellent customer service and fast turnaround times are the cornerstone of the service we provide. We maintain constant communication with our clients throughout every project to ensure products are delivered on time and to the highest quality standards, even when working to challenging deadlines.
When you choose Custom Designed Cables, you benefit from:
- Over 20 years of cable manufacturing expertise
- More than 6,000 bespoke cable designs completed
- Bespoke retractable cable design and manufacture
- ISO 9001:2015-certified quality management system
- UL and CSA-approved cable options
- Access to a comprehensive library of cable jacket materials and components
- Free technical consultation and advice
- Fast turnaround times
- Dedicated customer service throughout your project
From a single prototype to volume production, our team can manufacture retractable cables tailored to your exact specification.
Frequently asked questions
What is the difference between coiled cables and retractable cables?
There’s no difference. Coiled, curly, spiral and retractable cables all describe the same product: a cable formed into a helix that can extend and return to its resting length. The name varies from industry to industry, but the coiled construction offers the same benefits, preventing tangles, reducing strain on connections and keeping workspaces tidy.
How far can a retractable cable extend?
The extension length depends on the jacket material, coil diameter and intended use. Standard retractable cables extend a few metres, while specialist designs can reach up to 30 metres. PVC is generally used for shorter lengths, while PUR and Hytrel support longer extension ranges.
Are retractable cables durable?
Yes, provided they’re manufactured using the right materials for the application. PUR retractable cables retain their elasticity after thousands of extension and retraction cycles and offer excellent resistance to abrasion and chemicals, while Hytrel provides high resistance to mechanical stress in harsh conditions.
Is there a minimum order quantity for retractable cables?
It depends on the construction. Some of the materials we use are subject to minimum order quantities from our suppliers, which can affect both the minimum run and the lead time. Our team will confirm both when we quote for your project.
What details should I provide for a bespoke retractable cable?
We’ll need details such as the coil diameter, retracted length, tail lengths and finishes, number of cores, conductor sizes and the intended application. With this information, our engineers can recommend the most suitable materials, confirm feasibility and provide an accurate quote.
Get a quote for your retractable cables
Contact us today to discuss your retractable cable requirements and request a quote.
